AT-PTV-200EU is a compact yet powerful IPTV server designed to manage IPTV services and Android boxes efficiently. Equipped with dedicated software, it supports up to 200 users and 50 HD IPTV channels through 10 internet data ports. A built-in PMS enables small hotels to personalize the welcome screen with guest names, making it an ideal choice for small to medium-sized hotels aiming to maximize guest satisfaction.
Main Features:
- Protocol conversion among UDP/RTP/RTMP/HTTP/HLS and SRT
- Customizable logo for theme and live channels
- Easy channel lineup and grouping function
- Advertisement insertion via picture and video
- Automatic set-top box discovery and IP assignment within local network
- Remote software upgrade and user-experience control on STB
- Graphic user interface for easy configuration
Technical Specifications
| Item | Detail |
|---|---|
| Input Voltage | 90~264VAC, DC 12V 5A |
| Rack Space | 1RU |
| Input Connector | RJ45, 100/1000M Auto-Negotiate |
| Input Protocols | UDP/RTP/RTMP/HTTP/HLS/SRT |
| IP Addressing | Unicast and Multicast |
| Net Weight | 2.26 KG |
| Dimension | 482mm(W) x 44mm(H) x 260mm(D) |
